Meet the SK28SR Mini Excavator

Excavator performance with large portability, short radius agility and silent operation.

It has a Cooling System with a unique design from the brand.

COMPACT BUT RESISTANT

CHARACTERISTICS:

* Operating Weight: 2,950 Kg

* Engine: YANMAR 3TNV82A-B

* Engine power: 23 hp

* Bucket capacity: 0.08 m3

* Arm Length: 1.18 m

* Maximum digging reach: 4.89 m

* Maximum digging depth: 2.59 m

* Total length (Long): 4,550 mm

* Total height: 2,510 mm

* Total width: 1,550 mm

* Turning speed: 8.4 min-1 (rpm)

* Bucket breaking force: 24.7 KN - 2,419 Kgf.

* Arm drag force: 16.6 kn - 1,693 Kgf.

* Topped Blade (width/height): 1,550 / 345 (mm)

* Rubber shoe width: 300 mm

* Maximum transfer slope: 58% / 30 degrees

Wide working range: Larger boom and arm are offered as standard equipment to ensure a wider working range.

Short turning radius: The short turning radius of the tail improves operating efficiency in limited space.

Easy transportation: With a total height of 2510 mm, the machine is designed for easy transportation.
